Iglele MS Blind/Dummy Flange PN10 / PN16 – DIN EN 1092-1, Mild Steel
Iglele MS Blind/Dummy Flange PN10 / PN16 – DIN EN 1092-1, Mild Steel - Image 2
Iglele MS Blind/Dummy Flange PN10 / PN16 – DIN EN 1092-1, Mild Steel - Image 3

Iglele MS Blind/Dummy Flange PN10 / PN16 – DIN EN 1092-1, Mild Steel

IGLELEMake in India
Brand Make in India
Product Code MSFL16B
Availability 48 Hrs
Class/Table ND10/16
Standard/Pressure As Per BS-10,ASA,ISS OR DIN
Finish One Sided Machined
Material M.S (Mild Steel)

Flanges specifications, including pressure, temperature, and material, may vary between manufacturers and sizes; customers are urged to order accordingly.

Add to wishlist
SKU: MSFL16B
Availability:

1000 in stock

₹141.00 ₹99.00

Add to wishlist

🔵 MS Blind Flange – ND10 / ND16 (PN10 / PN16)

Industrial Blind Flanges | IGLELE – Industrial Goods Le Le 💼📦✨

🔷 Product Overview

IGLELE Mild Steel (MS) Blind Flanges – ND10 / ND16 are manufactured as per DIN / EN 1092-1 standards and are used to close pipeline ends, isolate flow, and provide hydro-test or inspection points in low to medium pressure piping systems.

Blind flanges are solid (without bore) and designed to withstand full line pressure, making them suitable for water, fire-fighting, oil, chemical, HVAC and general industrial pipelines.

  • ND10 / PN10 → 10 Bar pressure

  • ND16 / PN16 → 16 Bar pressure

🔷 MS Blind Flange – ND10 / ND16 Size Chart (Up to 36″)

DN / Inch Pipe OD (mm) Flange OD (mm) PCD (mm) Bolt Holes Bolt Dia (mm) Thickness (mm)
DN15 / ½” 21.3 95 65 4 14 18
DN20 / ¾” 26.9 105 75 4 14 18
DN25 / 1″ 33.7 115 85 4 14 20
DN32 / 1¼” 42.4 140 100 4 18 22
DN40 / 1½” 48.3 150 110 4 18 24
DN50 / 2″ 60.3 165 125 4 18 26
DN65 / 2½” 76.1 185 145 4 18 28
DN80 / 3″ 88.9 200 160 4 18 30
DN100 / 4″ 114.3 220 180 8 18 32
DN125 / 5″ 139.7 250 210 8 18 34
DN150 / 6″ 168.3 285 240 8 22 36
DN200 / 8″ 219.1 340 295 8 22 40
DN250 / 10″ 273.0 405 355 12 26 44
DN300 / 12″ 323.9 460 410 12 26 48
DN350 / 14″ 355.6 515 465 12 26 52
DN400 / 16″ 406.4 565 515 16 26 56
DN450 / 18″ 457.2 620 565 16 30 60
DN500 / 20″ 508.0 670 615 20 30 64
DN600 / 24″ 609.6 780 720 20 30 72
DN750 / 30″ 762.0 930 860 28 33 84
DN900 / 36″ 914.4 1080 1010 32 36 96

(DIN / EN 1092-1 – PN10 / PN16 | Blind Flanges – Commercial Thickness)

🔷 Standards & Compliance

  • DIN / EN 1092-1 – PN10 / PN16

  • IS 2062 / ASTM A36 (Material)

  • DIN / BS / ANSI blind flanges available on request

🔷 Material & Finish

  • Mild Steel (MS)

  • Carbon Steel

  • Stainless Steel (optional)

  • Black | Zinc Plated | Hot-Dip Galvanized

🔷 Facing

  • Flat Face (FF) – Standard

  • Raised Face (RF) – On request

🔷 Pressure & Temperature

  • Pressure Rating: PN10 / PN16

  • Suitable for moderate temperatures; pressure reduces with temperature rise

🔷 Applications

Pipeline end closure, pressure testing, maintenance isolation, water & fire lines, oil, chemical & utility pipelines

🔷 Custom Manufacturing – IGLELE

IGLELE manufactures Blind Flanges in DIN, BS & ANSI standards in:

  • MS, Carbon Steel

  • Stainless Steel

  • Alloy Steel & Duplex

Including special OD/PCD, heavy thickness and drawing-based manufacturing.

🔵 Order Now – Contact IGLELE

📞 +91 9800150888
📧 sales@iglele.com
🌐 www.iglele.com

Iglele – Industrial Goods Le Le 💼📦✨
