Rock Drill Rubber Hose – Heavy Duty Pneumatic Drill Hose (Per Meter)
Product Overview
| Parameter |
Details |
| Product Name |
Rock Drill Rubber Hose |
| Type |
Heavy Duty Pneumatic Drill Hose |
| Brand |
PHONEIX |
| Selling Unit |
Per Meter |
| Material |
Premium Synthetic Rubber with High-Tensile Textile Reinforcement |
| Working Media |
Compressed Air |
| Application |
Rock Drills, Pneumatic Tools & Mining Equipment |
Key Features
- Heavy-duty industrial rubber hose
- Designed for rock drills and pneumatic equipment
- High-tensile textile reinforced construction
- Excellent flexibility and durability
- Smooth inner tube for efficient airflow
- High abrasion-resistant outer cover
- Oil, weather, and ozone resistant
- Kink-resistant design
- High-pressure performance
- Suitable for rugged mining and construction environments
- Long service life
- Easy installation and maintenance
Size Chart
| Inner Diameter (ID) |
Outer Diameter (OD) |
Approx. Inch |
Supply |
| 13 mm |
21 mm |
1/2″ |
Per Meter |
| 16 mm |
25 mm |
5/8″ |
Per Meter |
| 19 mm |
29 mm |
3/4″ |
Per Meter |
| 25 mm |
36 mm |
1″ |
Per Meter |
| 32 mm |
44 mm |
1-1/4″ |
Per Meter |
Material
| Component |
Material |
| Inner Tube |
Oil-Resistant Synthetic Rubber |
| Reinforcement |
High-Tensile Textile Yarn |
| Outer Cover |
Abrasion, Weather & Ozone Resistant Rubber |
Where It Is Used / Applications
| Industry |
Application |
| Mining |
Rock Drilling |
| Construction |
Pneumatic Jack Hammers |
| Quarry Operations |
Air Drill Equipment |
| Tunnelling |
Compressed Air Supply |
| Infrastructure Projects |
Pneumatic Tools |
| Engineering Industry |
Air Operated Machinery |
| Shipyards |
Heavy Pneumatic Equipment |
| Industrial Plants |
Compressed Air Distribution |
How to Use
- Select the correct hose size for the equipment.
- Connect using compatible hose couplings.
- Tighten all connections securely.
- Supply clean, dry compressed air.
- Operate within the recommended pressure and temperature limits.
- Avoid twisting, crushing, or dragging over sharp edges.
- Inspect regularly and replace if damaged.
Technical Details & Specifications
| Specification |
Details |
| Product Type |
Rock Drill Pneumatic Rubber Hose |
| Material |
Synthetic Rubber |
| Reinforcement |
High-Tensile Textile Yarn |
| Construction |
Three-Layer Reinforced Hose |
| Working Media |
Compressed Air |
| Flexibility |
Excellent |
| Installation |
Hose Coupling Connection |
| Pressure Rating |
Depends on hose size and construction |
Construction Details
| Layer |
Description |
| Inner Layer |
Smooth Oil-Resistant Synthetic Rubber Tube |
| Middle Layer |
High-Tensile Textile Reinforcement |
| Outer Layer |
Abrasion & Weather Resistant Rubber Cover |
Available Standard Sizes
- 13 mm (1/2″)
- 16 mm (5/8″)
- 19 mm (3/4″)
- 25 mm (1″)
- 32 mm (1-1/4″)
Custom diameters and lengths available on request.
Advantages
- Heavy-duty industrial construction
- Excellent flexibility
- High-pressure capability
- Superior abrasion resistance
- Oil and weather resistant
- Long service life
- Smooth compressed air flow
- Easy installation
- Reliable performance in mining and construction
- Low maintenance
Temperature & Other Details
| Parameter |
Details |
| Working Temperature |
-20°C to +80°C |
| Working Media |
Compressed Air |
| Oil Resistance |
Excellent |
| Abrasion Resistance |
Excellent |
| Weather Resistance |
Excellent |
| UV Resistance |
Good |
| Outdoor Use |
Suitable |
| Working Pressure |
Depends on hose size and application |
Package Includes
| Item |
Quantity |
| Rock Drill Rubber Hose |
Per Meter (As Ordered) |
Custom Manufacturing & Bulk Orders
IGLELE offers:
- Custom hose diameters
- Custom hose lengths
- OEM & private label manufacturing
- Custom colours
- Bulk industrial supply
- Project-based manufacturing
- Wholesale and export orders
