Steam Rubber Hose – High Temperature Steam Transfer Hose
Steam Rubber Hose – High Temperature Steam Transfer Hose - Image 2
Steam Rubber Hose – High Temperature Steam Transfer Hose - Image 3

Steam Rubber Hose – High Temperature Steam Transfer Hose

Phoneix
Specification Details
Brand PHONEIX
Product Code / SKU HT1
Availability Ready Stock – Dispatch within 24–48 Hours
Material Premium EPDM Synthetic Rubber with High-Tensile Textile / Steel Wire Reinforcement
Supply Length Per Meter
Temperature Range -40°C to +100°C
Colour Black
Application Steam Transfer, Hot Water Supply, Boiler Systems, Steam Cleaning Equipment, Chemical Plants, Textile Industry, Food Processing, Refineries & Industrial Heating Applications
SKU: HT1
Availability:

100 in stock

₹609.00 ₹426.30

Steam Rubber Hose – High Temperature Steam Transfer Hose

Product Overview

Parameter Details
Product Name Steam Rubber Hose
Type High Temperature Steam Transfer Hose
Brand PHONEIX
Selling Unit Per Meter
Material EPDM Synthetic Rubber with High-Tensile Steel Wire / Textile Reinforcement
Working Media Saturated Steam & Hot Water
Application Steam Transfer, Industrial Heating & Cleaning Systems

Key Features

  • Premium EPDM synthetic rubber construction
  • Designed for saturated steam and hot water service
  • High-temperature resistant
  • Reinforced with high-tensile textile or steel wire
  • Excellent flexibility and durability
  • Superior abrasion and weather resistance
  • Smooth inner tube for efficient steam flow
  • Kink-resistant construction
  • Ozone and heat resistant
  • Leak-resistant performance
  • Long service life
  • Suitable for heavy-duty industrial applications

Size Chart

Inner Diameter (ID) Approx. Inch Supply
13 mm 1/2″ Per Meter
19 mm 3/4″ Per Meter
25 mm 1″ Per Meter
32 mm 1-1/4″ Per Meter
38 mm 1-1/2″ Per Meter
50 mm 2″ Per Meter

Material

Component Material
Inner Tube Heat-Resistant EPDM Synthetic Rubber
Reinforcement High-Tensile Textile Yarn / Steel Wire
Outer Cover EPDM Rubber – Heat, Ozone & Abrasion Resistant

Where It Is Used / Applications

Industry Application
Food Processing Steam Cleaning
Chemical Plants Steam Transfer
Textile Industry Steam Supply
Refineries Steam Lines
Pharmaceutical Plants Sterilization Systems
Paper Mills Steam Heating
Sugar Mills Process Steam
Industrial Boilers Steam Distribution

How to Use

  1. Select the correct hose size for the application.
  2. Connect using steam-rated hose fittings and clamps.
  3. Tighten all connections securely.
  4. Gradually introduce steam pressure.
  5. Operate within the recommended pressure and temperature limits.
  6. Allow the hose to cool before handling after use.
  7. Inspect regularly for wear or damage and replace if necessary.

Technical Details & Specifications

Specification Details
Product Type Steam Rubber Hose
Material EPDM Synthetic Rubber
Reinforcement Textile Yarn / Steel Wire
Construction Three-Layer Reinforced Hose
Working Media Saturated Steam & Hot Water
Flexibility Excellent
Installation Steam Hose Couplings
Pressure Rating Depends on hose size and model

Construction Details

Layer Description
Inner Layer Heat-Resistant EPDM Rubber Tube
Middle Layer High-Tensile Reinforcement
Outer Layer Abrasion, Heat & Weather Resistant EPDM Cover

Available Standard Sizes

  • 13 mm (1/2″)
  • 19 mm (3/4″)
  • 25 mm (1″)
  • 32 mm (1-1/4″)
  • 38 mm (1-1/2″)
  • 50 mm (2″)

Supply: Per Meter

Custom sizes and lengths available on request.

Advantages

  • Excellent high-temperature resistance
  • Reliable steam transfer
  • High-pressure capability
  • Flexible and easy to install
  • Superior abrasion resistance
  • Heat and ozone resistant
  • Long service life
  • Heavy-duty industrial construction
  • Low maintenance
  • Suitable for continuous industrial operation

Temperature & Other Details

Parameter Details
Working Temperature -40°C to +100°C
Hot Water Temperature Up to +120°C
Working Media Saturated Steam & Hot Water
Heat Resistance Excellent
Abrasion Resistance Excellent
Ozone Resistance Excellent
Outdoor Use Suitable
Safety Use only with steam-rated couplings and fittings

Package Includes

Item Quantity
Steam Rubber Hose Per Meter (As Ordered)

Custom Manufacturing & Bulk Orders

PHONEIX / IGLELE offers:

  • Custom hose diameters
  • Custom hose lengths
  • OEM & private label manufacturing
  • Steam-rated coupling options
  • Bulk industrial supply
  • Export and wholesale orders
  • Project-based steam transfer solutions

Contact IGLELE for Bulk & Custom Orders

IGLELE E Commerce LLP

Website: IGLELE.com
Phone: +91 9800150888
Email: sales@iglele.com

Contact IGLELE for bulk pricing, OEM manufacturing, custom steam hoses, industrial steam transfer systems, boiler hose solutions, and high-temperature fluid transfer applications.
