Thermally Insulated Aluminium Foil Duct Hose – Flexible HVAC Insulated Air Duct (7.5 Meter)

Phoneix
Specification Details
Brand PHONEIX
Product Code / SKU ALLIL
Availability Ready Stock – Dispatch within 24–48 Hours
Material Aluminium Foil, Thermal Insulation Layer & Spiral Steel Wire Reinforcement
Length 7.5 Meter
Temperature Range -30°C to +140°C
Colour Silver Aluminium Finish
Application HVAC Systems, Air Conditioning, Ventilation, Fresh Air Supply, Return Air Ducting, Commercial & Industrial Air Distribution
SKU: ALLIL
Availability:

100 in stock

₹3,625.00 ₹2,537.50

Thermally Insulated Aluminium Foil Duct Hose – Flexible HVAC Insulated Air Duct (7.5 Meter)

Product Overview

Parameter Details
Product Name Thermally Insulated Aluminium Foil Duct Hose
Type Flexible Insulated HVAC Air Duct
Standard Length 7.5 Meter
Material Aluminium Foil + Thermal Insulation + Spiral Steel Wire
Application HVAC, Air Conditioning, Ventilation & Air Distribution
Temperature Range Approx. -30°C to +140°C*
Brand PHONEIX
Custom Sizes Available

Temperature may vary depending on insulation material and construction.

Key Features

  • Excellent thermal insulation performance
  • Reduces heat loss and condensation
  • Flexible and lightweight construction
  • Reinforced spiral steel wire for strength
  • Easy to install in confined spaces
  • Suitable for HVAC supply and return air
  • Corrosion-resistant aluminium outer layer
  • Energy-efficient air distribution
  • Low maintenance
  • Available in multiple sizes

Size Chart

Diameter (MM) Inch Standard Length
80 mm 3″ 7.5 Meter
100 mm 4″ 7.5 Meter
125 mm 5″ 7.5 Meter
150 mm 6″ 7.5 Meter
200 mm 8″ 7.5 Meter
250 mm 10″ 7.5 Meter
300 mm 12″ 7.5 Meter

Material

Component Material
Inner Duct Aluminium Foil
Insulation Thermal Glass Wool / Polyester Insulation*
Reinforcement High Tensile Spiral Steel Wire
Outer Jacket Aluminium Foil Laminate

*Construction may vary by model.

Where It Is Used / Applications

Industry Application
HVAC Systems Air Supply & Return Air
Air Conditioning Insulated Air Distribution
Commercial Buildings Ventilation Systems
Industrial Plants Fresh Air Supply
Shopping Malls Central Air Conditioning
Hospitals Clean Air Distribution
Hotels HVAC Ducting
Offices Air Circulation
Residential Buildings Ventilation Systems
Data Centres Cooling Air Distribution

How to Use

  1. Select the required duct diameter.
  2. Extend the hose carefully.
  3. Connect to duct collars or outlets.
  4. Secure both ends with duct clamps.
  5. Seal joints with aluminium foil tape if required.
  6. Support long duct runs properly.
  7. Avoid crushing or excessive bending.

Technical Details

Specification Details
Product Type Insulated Flexible Air Duct
Length 7.5 Meter
Temperature -30°C to +120°C*
Insulation Thermal Insulation Layer
Construction Multi-Layer Flexible Duct
Reinforcement Spiral Steel Wire
Air Flow Hot & Cold Air
Installation HVAC Duct Systems

Construction Details

Layer Description
Inner Layer Aluminium Foil Air Duct
Middle Layer Thermal Insulation
Reinforcement Spiral Steel Wire
Outer Layer Protective Aluminium Foil Jacket

Available Standard Sizes

  • 80 mm (3″)
  • 100 mm (4″)
  • 125 mm (5″)
  • 150 mm (6″)
  • 200 mm (8″)
  • 250 mm (10″)
  • 300 mm (12″)

Custom diameters available on request.

Advantages

  • Excellent thermal insulation
  • Prevents heat loss
  • Reduces condensation
  • Energy-efficient HVAC performance
  • Lightweight construction
  • Highly flexible
  • Easy installation
  • Durable multi-layer construction
  • Long service life
  • Suitable for residential, commercial and industrial HVAC systems

Temperature & Other Details

Parameter Details
Working Temperature Approx. -30°C to +120°C*
Insulation High Thermal Efficiency
Air Media Hot & Cold Air
UV Resistance Limited (Indoor Recommended)
Flame Contact Not Suitable
Installation Indoor HVAC Systems

Actual temperature depends on insulation type and manufacturer specifications.

Package Includes

Item Quantity
Thermally Insulated Aluminium Foil Duct Hose 1 No.
Standard Length 7.5 Meter

Clamps and connectors are supplied separately unless specified.

Custom Manufacturing & Bulk Orders

IGLELE offers custom manufacturing for:

  • Custom diameters
  • Custom lengths
  • Special insulation thickness
  • OEM branding
  • Bulk industrial orders
  • Project supply

Contact IGLELE for Bulk & Custom Orders

IGLELE E Commerce LLP

Website: IGLELE.COM
Phone: +91 9800150888
Email: sales@iglele.com

Contact IGLELE for bulk pricing, OEM manufacturing, project enquiries, custom sizes, and industrial HVAC duct solutions.
