Aluminium Foil Flexible Duct Hose 250°C – High Temperature Exhaust Hose (10 Meter)
| Specification | Details |
|---|---|
| Brand | PHONEIX |
| Product Code / SKU | ALL2 |
| Availability | Ready Stock – Dispatch within 24–48 Hours |
| Material | Aluminium Foil with Flexible Reinforced Construction |
| Temperature | Up to 250°C |
| Length | 10 Meter |
| Colour | Silver / Aluminium Finish |
| Application | Hot Air Exhaust, Fume Extraction, HVAC, Industrial Ventilation & Exhaust Systems |
100 in stock
₹3,480.00 ₹2,436.00
Aluminium Foil Flexible Duct Hose 250°C – High Temperature Exhaust Hose (10 Meter)
Product Overview
| Parameter | Details |
|---|---|
| Product Name | Aluminium Foil Flexible Duct Hose |
| Type | Flexible High-Temperature Exhaust / Ventilation Duct |
| Standard Length | 10 Meter |
| Maximum Temperature | Up to 250°C* |
| Material | Aluminium Foil with Reinforced Flexible Construction |
| Structure | Corrugated / Spiral Flexible Duct |
| Flexibility | High |
| Application | Hot Air, Exhaust, Fume Extraction & Ventilation |
| Brand / Make | IGLELE |
| Custom Sizes | Available on Bulk Order |
*Actual continuous working temperature can vary depending on the exact foil thickness, reinforcement, construction, airflow, pressure, and installation conditions.
Key Features
- High-temperature resistance up to 250°C
- Lightweight and highly flexible construction
- Easy to bend and route in confined spaces
- Suitable for hot-air and exhaust-air transfer
- Flexible design helps simplify duct installation
- Can be compressed or extended depending on construction
- Suitable for industrial ventilation and fume extraction
- Easy connection with suitable duct clamps
- Available in multiple diameters
- Suitable for custom and bulk requirements
Size Chart
| Nominal Diameter | Approx. Inch Size | Standard Length |
|---|---|---|
| 50 mm | 2″ | 10 Meter |
| 63 mm | 2½” | 10 Meter |
| 75 mm | 3″ | 10 Meter |
| 100 mm | 4″ | 10 Meter |
| 125 mm | 5″ | 10 Meter |
| 150 mm | 6″ | 10 Meter |
| 200 mm | 8″ | 10 Meter |
| 250 mm | 10″ | 10 Meter |
| 300 mm | 12″ | 10 Meter |
Note: Size availability should be confirmed before ordering. Custom diameters and lengths may be supplied for bulk requirements.
Material & Construction Details
| Component | Material / Construction | Purpose |
|---|---|---|
| Outer Body | Aluminium Foil | Lightweight heat-resistant ducting |
| Duct Wall | Multi-layer / reinforced foil construction* | Provides flexibility and airflow passage |
| Reinforcement | Spiral reinforcement wire* | Helps maintain circular duct shape |
| Surface | Corrugated Flexible Structure | Allows bending and routing |
| End Connection | Open Flexible Duct Ends | Suitable for clamp-based installation |
*Exact construction may vary by model and manufacturing specification.
Applications – Where It Is Used
| Industry / Area | Application |
|---|---|
| Industrial Ventilation | Removal and transfer of hot air |
| Exhaust Systems | Exhaust-air ducting |
| HVAC Systems | Air distribution and ventilation |
| Workshops | Fume and hot-air extraction |
| Machinery | Ventilation around heat-generating equipment |
| Factories | Process air and exhaust ventilation |
| Automotive Workshops | General exhaust and ventilation applications |
| Welding Areas | Fume extraction when used with a suitable extraction system |
| Drying Systems | Hot-air circulation and transfer |
| Commercial Kitchens | Ventilation applications where compatible with system requirements |
How to Use
- Select the correct duct diameter according to the inlet or outlet connection.
- Extend the flexible hose carefully to the required length.
- Route the duct without excessive crushing or sharp bends.
- Fit the hose over the exhaust, ventilation, or air outlet.
- Secure both ends using suitable duct clamps or connectors.
- Ensure the duct does not touch surfaces exceeding its rated temperature.
- Inspect the hose periodically for tears, crushing, loose connections, or heat damage.
Technical Details & Specifications
| Specification | Details |
|---|---|
| Product Type | Flexible Aluminium Foil Duct Hose |
| Temperature Rating | Up to 250°C* |
| Standard Length | 10 Meter |
| Available Diameter | Multiple Standard Sizes |
| Construction | Flexible Corrugated / Spiral Reinforced* |
| Main Material | Aluminium Foil |
| Installation | Clamp / Connector Based |
| Primary Media | Air, Hot Air, Exhaust Air and Ventilation Fumes |
| Flexibility | High |
| Custom Manufacturing | Available Subject to Quantity |
Temperature & Other Details
| Parameter | Details |
|---|---|
| Maximum Temperature | Up to 250°C* |
| Recommended Use | Hot-air and exhaust ventilation |
| Direct Flame Contact | Not Recommended |
| High-Pressure Use | Not Recommended unless specifically rated |
| Abrasive Material Transfer | Not Recommended |
| Chemical Compatibility | Must be checked according to the chemical/fume being handled |
| Installation Condition | Avoid sharp edges, excessive compression and tight bends |
Important: The 250°C rating should be confirmed as either continuous or intermittent temperature from the exact manufacturer’s technical specification before publishing it as a guaranteed continuous operating temperature.
Advantages
- Lightweight construction
- Flexible and easy to install
- Suitable for difficult routing areas
- Good temperature resistance
- Easy handling and transportation
- Wide range of diameter options
- Suitable for industrial and commercial ventilation
- Can reduce the need for multiple rigid duct bends
- Custom sizes can be manufactured for bulk requirements
Available Standard Sizes
Standard diameters can include 50 mm, 63 mm, 75 mm, 100 mm, 125 mm, 150 mm, 200 mm, 250 mm and 300 mm, subject to availability. Other sizes can be offered against specific requirements and minimum order quantity.
Package Includes
| Item | Quantity |
|---|---|
| Aluminium Foil Flexible Duct Hose | 1 No. |
| Standard Hose Length | 10 Meter |
Clamps, connectors, reducers, and other accessories are generally supplied separately unless specifically included in the quotation.
Custom Manufacturing & Bulk Orders
IGLELE can support custom and bulk requirements for Aluminium Foil Flexible Duct Hoses. Customers can enquire for different diameters, lengths, construction requirements, temperature requirements, and bulk quantities, subject to manufacturing feasibility and minimum order quantity.
Contact IGLELE for Bulk & Custom Orders
IGLELE E Commerce LLP
Website: IGLELE.com
Phone: 9800150888
Email: sales@iglele.com
Contact IGLELE for bulk quantity, custom sizes, industrial requirements, quotations, and availability.
