Iglele MS Screwed Flange BS 10 Table E – BSP Threaded Mild Steel
Iglele MS Screwed Flange BS 10 Table E – BSP Threaded Mild Steel - Image 2

Iglele MS Screwed Flange BS 10 Table E – BSP Threaded Mild Steel

IGLELEMake in India
Brand Make in India
Product Code MSSFET
Availability 48 Hrs
Class/Table E Table
Standard/Pressure As Per BS-10,ASA,ISS OR DIN
Finish One Sided Machined
Material M.S (Mild Steel)

Flanges specifications, including pressure, temperature, and material, may vary between manufacturers and sizes; customers are urged to order accordingly.

SKU: MSSFET
Availability:

1000 in stock

₹119.00 ₹71.00

🔵 MS Screwed (Threaded) Flange – BS 10 Table E (PN16)

Medium-Pressure Threaded Flanges | IGLELE – Industrial Goods Le Le 💼📦✨

🔷 Product Overview

IGLELE Mild Steel (MS) Screwed Flanges – Table E are manufactured as per BS 10 – Table E (PN16) and are designed for 16 Bar pressure systems where welding is not preferred.

These flanges feature internal BSP / BSPT / NPT threads and are commonly used in:

  • Water & utility pipelines

  • Fire-fighting systems

  • HVAC and compressed air lines

  • Maintenance & temporary piping

  • Low-vibration industrial services

Screwed flanges allow easy installation, dismantling and maintenance without hot work.

🔷 MS Screwed Flange – BS 10 Table E Size Chart (Up to 36″)

⚠️ Screwed flanges are commonly used up to 6″–8″. Sizes above this range are supplied only on special request for specific applications.

NB (Inch) Thread Type Pipe OD (mm) Flange OD (mm) PCD (mm) Bolt Holes Bolt Dia (mm) Thickness (mm)
½” BSP / BSPT / NPT 21.3 95 67 4 16 16
¾” BSP / BSPT / NPT 26.7 105 75 4 16 16
1″ BSP / BSPT / NPT 33.4 115 85 4 16 18
1¼” BSP / BSPT / NPT 42.2 140 100 4 16 18
1½” BSP / BSPT / NPT 48.3 150 110 4 16 20
2″ BSP / BSPT / NPT 60.3 165 125 4 16 22
2½” BSP / BSPT / NPT 73.0 185 145 4 16 22
3″ BSP / BSPT / NPT 88.9 200 160 4 16 24
4″ BSP / BSPT / NPT 101.6 220 180 8 16 24
5″ BSP / BSPT / NPT 127.0 250 210 8 16 26
6″ BSP / BSPT / NPT 152.4 285 240 8 20 26
8″* BSP / BSPT / NPT 219.1 340 295 8 20 28
10″* BSP / BSPT / NPT 273.0 405 355 12 20 30
12″* BSP / BSPT / NPT 323.9 460 410 12 20 32
14″* BSP / BSPT / NPT 355.6 515 465 12 24 34
16″* BSP / BSPT / NPT 406.4 565 515 16 24 36
18″* BSP / BSPT / NPT 457.2 620 565 16 24 38
20″* BSP / BSPT / NPT 508.0 670 615 20 24 40
24″* BSP / BSPT / NPT 609.6 780 720 20 24 44
30″* BSP / BSPT / NPT 762.0 930 860 28 24 50
36″* BSP / BSPT / NPT 914.4 1080 1010 32 24 56

*Sizes above 6″ are non-standard for screwed flanges and supplied only against confirmed drawings or applications.

🔷 Standards & Compliance

  • BS 10 – Table E (PN16)

  • IS 1538

  • IS 2062 / ASTM A36 (Material)

  • Threads: BSP (ISO 7/1), BSPT or NPT (ASME B1.20.1)

🔷 Material & Finish

  • Mild Steel (MS)

  • Carbon Steel (optional)

  • Stainless Steel (optional)

  • Black | Zinc Plated | Hot-Dip Galvanized

🔷 Facing & Threads

  • Facing: Flat Face (FF) standard

  • Thread Options: BSP / BSPT / NPT

🔷 Pressure & Temperature

  • Pressure Rating: PN16 (16 Bar)

  • Recommended for low vibration & moderate temperature services

  • Not suitable for high cyclic loads without locking arrangements

🔷 Applications

Water lines, fire-fighting systems, HVAC, compressed air, maintenance piping, utility services

🔷 Custom Manufacturing – IGLELE

IGLELE manufactures Screwed, Slip-On, Weld-Neck & Blind flanges in BS, DIN & ANSI standards, offering:

  • Special thread forms

  • Extra thickness

  • Drawing-based manufacturing

  • OEM & project supply

🔵 Order Now – Contact IGLELE

📞 +91 9800150888
📧 sales@iglele.com
🌐 www.iglele.com

Iglele – Industrial Goods Le Le 💼📦✨
